Cutter Suction Dredger JLCSD250
This cutter suction dredger is widely used in rivers, lakes, ports, and inland waterways. It can dredge sand, mud, and gravel from all kinds of dredging projects. Equipped with high-quality devices, this model ensures maximum performance while minimizing operational costs. Customers can achieve the highest profit with configurations such as Cummins diesel engines (alternatively Carter, Weichai, or other brands), Shijiazhuang slurry pumps, and hydraulic pumps from the USA or Germany. All components are designed for low failure, low fuel consumption, high capacity, and high efficiency.
This cutter suction dredger is widely used in rivers, lakes, ports, and inland waterways. It can dredge sand, mud, and gravel from all kinds of dredging projects. Equipped with high-quality devices, this model ensures maximum performance while minimizing operational costs. Customers can achieve the highest profit with configurations such as Cummins diesel engines (alternatively Carter, Weichai, or other brands), Shijiazhuang slurry pumps, and hydraulic pumps from the USA or Germany. All components are designed for low failure, low fuel consumption, high capacity, and high efficiency.
— Technical Specifications
|
JLCSD250 Cutter Suction Dredger General Specifications |
|||
|
OA Length(Ladder included) |
23.5m |
Flow Capacity |
800m³/hr |
|
Hull Width |
5.2m |
Standard Dredging Depth |
10m |
|
Hull Depth |
1.6m |
Discharge Distance |
800m |
|
Draft |
1.0m |
Suction Pipe Diameter |
250mm |
|
Cutter Head Power |
40kw |
Discharge Pipe Diameter |
250mm |
|
Engine Power |
336kw |
Customized Design is Available |
|
— Application
Ideal for rivers, lakes, ports, and waterways, this dredger efficiently handles sand dredging. Equipped with Cummins diesel engines, Shijiazhuang slurry pumps, and high-quality hydraulic systems, it delivers high capacity, low fuel consumption, and reliable performance.
— Advantage
High efficiency and large output for sand dredging.
Reliable diesel engine, slurry pump, and hydraulic system from international brands.
Siemens PLC one-man operation for convenience and precision.
Modular design allows fast assembly and easy transportation.
Tested before delivery to ensure smooth performance.
— Service
Design & Engineering: Customized design to meet small-scale sand dredging needs.
Pre-Delivery Testing: Fully assembled and rigorously tested before delivery.
On-Site Installation: Engineers assist with installation for fast setup.
Operation Training: Hands-on training ensures smooth and safe operation.
Maintenance & Repair: Free repairs within warranty; ongoing support available.
Spare Parts & Upgrades: Modular design enables easy transport; spare parts readily available.
