Cutter Suction Dredger JLCSD850
This model is ideal for port construction and navigation channel maintenance. It can dredge sand, mud, clay, silt, and other sediments to ensure safe passage for vessels. With advanced configurations and high-quality components, it achieves low fuel consumption, low failure rate, high capacity, and efficient performance. The dredger is an indispensable asset for both large-scale infrastructure projects and environmental-friendly dredging operations.
This model is ideal for port construction and navigation channel maintenance. It can dredge sand, mud, clay, silt, and other sediments to ensure safe passage for vessels. With advanced configurations and high-quality components, it achieves low fuel consumption, low failure rate, high capacity, and efficient performance. The dredger is an indispensable asset for both large-scale infrastructure projects and environmental-friendly dredging operations.
— Technical Specifications
|
JLCSD850 Cutter Suction Dredger General Specifications |
|||
|
OA Length(Ladder included) |
72m |
Flow Capacity |
8500-10000m³/hr |
|
Hull Width |
11.8m |
Standard Dredging Depth |
22m |
|
Hull Depth |
3.3m |
Discharge Distance |
4000m |
|
Draft |
6.8m |
Suction Pipe Diameter |
800mm |
|
Cutter Head Power |
1100kw |
Discharge Pipe Diameter |
750mm |
|
Engine Power |
6342kw |
Customized Design is Available |
|
— Application
A versatile solution for sand, mud, construction, mining, and environmental dredging. Perfect for ports and navigation channels, it offers low fuel consumption, high efficiency, and reliable operation in various water environments.
— Advantage
Versatile for sand, mud, construction, mining, and environmental dredging.
Low fuel consumption with high working efficiency.
World-class parts: Cummins diesel engine, Siemens PLC system, Shijiazhuang pump.
One-man operation with simple and fast assembly.
Standard design and optional equipment allow flexible, reliable operation.
— Service
Design & Engineering: Versatile design for sand, mud, construction, mining, and environmental applications.
Pre-Delivery Testing: Fully assembled and pool-tested for reliable operation.
On-Site Installation: Engineers guide assembly and commissioning on-site.
Operation Training: Comprehensive operation and maintenance training.
Maintenance & Repair: Full warranty, preventive maintenance, and 24/7 support.
Spare Parts & Upgrades: Readily available spare parts and optional upgrades for long-term efficiency.
